Brand Name : | HUITONG |
Model Number : | Grapple |
Price : | $2000-$3500 |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability : | 200sets/month |
Delivery Time : | 7-10 work days |
Machine Tonnage | Description | Max.Opening ranging(in) | Weight(lbs) | Material |
6-10T | Rotating/non-rotating | 57.1 | 1430/1562 | Q690+NM360 |
11-16T | Rotating/non-rotating | 66.9 | 1760/1914 | Q690+NM360 |
17-20T | Rotating/non-rotating | 74.8 | 2134/2310 | Q690+NM360 |
21-24T | Rotating/non-rotating | 80.7 | 2354/2530 | Q690+NM360 |
25-30T | Rotating/non-rotating | 86.6 | 2640/2860 | Q690+NM360 |
31-35T | Rotating/non-rotating | 90.6 | 3080/3344 | Q690+NM360 |
36-40T | Rotating/non-rotating | 94.5 | 3630/3938 | Q690+NM360 |
41-45T | Rotating/non-rotating | 98.4 | 4268/4620 | Q690+NM360 |
65T | Rotating/non-rotating | 98.4 | 8140/9240 | Q690+NM360 |
Advantages
1. Removable Teeth, Include removable teeth so it is easy to
repalce the main wearing parts.
2. wear faces, All high wear faces ahve wear plate, increasing the life of your Rock Grapple.
3. Rotating bearing and famous brand hydraulic motor.
4. High capacity ram with integrated check valve.
5. nsuring the best grabbing capabilities and nothing can be dropped.Two or one hydraulic.
![]() |
